Rotating
demolition & sorting grabs
Exchangeable
wear parts
The new ProLine DLP-models in the dedicated demolition line are special designed to have a competitive rotatable pulveriser in the market with the full Demarec DNA.
It’s a concept with mostly new exchangeable wear parts. Also these new pulverisers can be used in primary and secondary demolition.
no concessions
to quality
With this new line of pulverizers we are focusing on a new target group. The pulverizers are intended for 32 tons excavators down to 9 ton. During the development we have not made any concessions to quality, but have mainly looked at possibilities to develop a product with a more advantageous final price for the customer.
standard
cylinder
The ProLine, which is marketed under the name Demarec ProLine, has a simpler, standard cylinder technology and a different technical structure, including a different tooth plate system. The Demarec philosophy of fully exchangeable wear parts has also been implemented in the new DLP line.
Exceptional
price to performance
The Demarec DNA
Trendsetter
Trendsetter in
product developments
Knowledge
Technical and market knowledge in perfect harmony
New generation components
A lead over the competition due to the use of a new generation of components
Superior quality
Superior quality at market prices
Sustainability
Focus on sustainability
Low operating costs
Supplier of equipment with low operating costs
Greater longevity
Faster, higher capacity, less maintenance, low fuel consumption, greater longevity and interchangeable components
KINSHOFER GROUP
Part of the KINSHOFER GROUP
Key features & benefits
rotation
Double rotation motors from DSG-16-DN (optional DSG-14-DN)
Shock protection
360-degree rotation with shock protection
Visibility
Perforated shells, excellent operator visibility
cylinder design
Stationary cylinder design reduces hose movement
Top plate
Bolt on mounting top plate
1 or 2 Cylinders
1 cylinder DSG-2-DN until DSG-14-DN, 2 cylinders from DSG-16-DN
Exchangeable
Bolt on exchangeable blades
| Type | Unit | DSG-2-DN PRO | DSG-5-DN PRO | DSG-6-DN PRO | DSG-9-DN PRO | DSG-14-DN PRO | DSG-16-DN PRO | DSG-20-DN PRO | DSG-25-DN PRO |
|---|---|---|---|---|---|---|---|---|---|
| Carrier weight* | lbs | 4400-7700 | 7700-9900 | 8800-12000 | 11000-20000 | 22000-33000 | 28000-40000 | 33000-46000 | 37000-62000 |
| Weight (approx.)** | lbs | 320 | 540 | 904 | 981 | 1742 | 2072 | 2260 | 3296 |
| Capacity | gal | 26 | 40 | 53 | 66 | 106 | 132 | 159 | 211 |
| Opening | inch | 31 | 46 | 55 | 61 | 69 | 77 | 77 | 80 |
| Width | inch | 18 | 20 | 24 | 28 | 31 | 31 | 35 | 40 |
| Height | inch | 28 | 32 | 38 | 39 | 45 | 49 | 49 | 55 |
| Cylinders | No | 1 | 1 | 1 | 1 | 1 | 2 | 2 | 2 |
| Open/Closing Pmax | psi | 3626 | 4061 | 4351 | 4351 | 4641 | 4641 | 5076 | 5076 |
| Flow | gpm | 5 | 7 | 11 | 13 | 26 | 32 | 32 | 45 |
| Rotation Pmax | psi | 1740 | 1740 | 2031 | 2031 | 2031 | 2031 | 2031 | 2031 |
| Flow | gpm | 1 | 1 | 1 | 1 | 2-4*** | 4*** | 4*** | 5*** |
